品牌:德国莱克LIK品牌
型号:LIK
规格:DN15-DN200
起订:1台
供应:1000台
发货:3天内
产品特点：
不锈钢阀芯，在长时间不动作情况下启动阀门，动作迅速，快速切断；线圈长时间通电，发热量低，不会烧毁，功耗底，节能；零压启动，零泄漏。
Applications:
It is widely used in industrial furnaces, boilers, gas pipelines, gas treatment plants, filling stations, gas leak alarm systems, security systems, fire alarm systems, explosive media, cut off the city or the factory; when that potential accidents Quick cut, time to stop fatal accidents.
Features:
Stainless steel spool, the situation does not move in a long time to start valves, quick action, quick cut; coil for a long time power, low heat, not burning, power bottom, energy saving; zero pressure starts, zero leakage.
主要技术参数：
|
产品规格： |
DN15--DN200 |
|
阀体材质： |
铸钢体、不锈钢（铸钢体不能用在腐蚀流体上） |
|
适用介质： |
煤气、天然气、液化气、沼气、甲烷、瓦斯等气体或燃油 |
|
温度范围： |
-20～+100℃ |
|
防护性能： |
防水、防爆（Exd IICT5) |
|
接线方式： |
引线式；接线座式；插头式 |
|
电源电压： |
DC12～127V; AC36～380V |
|
连接方式： |
管接，法兰 |
Main technical parameters:
|
Specifications: |
DN15 - DN200 |
|
Body material: |
Steel body, stainless steel (steel body can not be used in corrosive fluid on) |
|
Medium: |
Gas, natural gas, liquefied petroleum gas, biogas, methane, gas and other gas or fuel oil |
|
Temperature range: |
-20 ~ +100 ℃ |
|
Protection performance: |
Waterproof, explosion-proof (Exd IICT5) |
|
Wiring: |
Lead type; Terminal Block type; male |
|
Power supply voltage: |
DC12 ~ 127V; AC36 ~ 380V |
|
Connection: |
Pipe connection, flange |
