品牌:德国莱克LIK品牌
型号:LIK
规格:标准
起订:1台
供应:1000台
发货:3天内
产品特点：
阀芯均为不锈钢材料、活塞式结构；动作响应迅速；专制线圈，采取防水方式，不易烧毁；长时间停止动作重新启动，动作同样灵敏；使用寿命长达100万次以上。
主要技术参数：
|
产品规格： |
DN15--DN300 |
|
阀体材质： |
铸钢体、不锈钢（铸钢体不能用在腐蚀流体上） |
|
适用介质： |
水、气、油、腐蚀流体等 |
|
温度范围： |
-20～+100℃ |
|
介质粘度： |
小于50C St(大于时需定制） |
|
防护性能： |
防水、防爆（Exd IICT5)、防腐 |
|
接线方式： |
引线式 |
|
控制方式： |
常开、常闭 |
|
电源电压： |
DC24～127V; AC36～380V |
|
连接方式： |
内螺纹、法兰（外螺纹和特殊接口可定做或加转接头） |
|
泄 漏 量： |
零 |
Applications:
It is mainly used in landscape irrigation, shipping heavy industry, petrochemical industry, urban water supply and drainage, cleaning equipment, water and other piping systems.
Features:
Are all stainless steel valve, piston structure; action to respond quickly; authoritarian coil, to take water way and difficult to burn; a long time to re-start stop action, action as sensitive; life of up to 100 million times.
Main technical parameters:
|
Specifications: |
DN15 - DN300 |
|
Body material: |
Steel body, stainless steel (steel body can not be used in corrosive fluid on) |
|
Medium: |
Water, gas, oil, corrosive fluids |
|
Temperature range: |
-20 ~ +100 ℃ |
|
Media Viscosity: |
Less than 50C St (greater than the time to be customized) |
|
Protection performance: |
Waterproof, explosion-proof (Exd IICT5), anti-corrosion |
|
Wiring: |
Leaded |
|
Control: |
Normally open, normally closed |
|
Power supply voltage: |
DC24 ~ 127V; AC36 ~ 380V |
|
Connection: |
Thread, flange (male and special interfaces or add custom adapter) |
|
Leakage: |
Zero |
